Leica BLK360 Gen1 Imaging Laser Scanner £15360.00 Detailed Description
When you truly grasp reality, possibilities come to light
The Leica BLK360 is the world’s smallest imaging laser scanner, simplifying the collection of accurate 3D imagery and measurements.
The BLK360 shoots 360˚ high dynamic range (HDR) spherical imagery and combines it with an accurate 3D laser point-cloud.
Designed to simplify the reality capture process, the BLK360 has only one button and produces digital reality data in under 3 minutes.
Its 0.5 - 60 metre range and optimisation for both indoor and outdoor use makes it the ideal close to-mid range reality capture device.
This compact 3D scanner uses laser 3D scanning technology to capture its environment in 3D. In addition to its LIDAR (Light Detection and Ranging) sensor the BLK360 offers infrared sensors for thermal imaging and 360˚ images.
Using the ReCAP Pro 360 mobile app, the BLK360 streams image and point cloud data to an iPad. The app then filters and registers scan data in real-time. After capture, ReCap 360 enables the point cloud data to be transferred to a number of CAD, BIM, VR and AR applications.
All this comes in a battery-powered, black aluminium device that’s light and small enough to fit into your hand.
Features & Benefits
Imaging Scanner | 3D Laser with integrated spherical imaging system and thermography panorama sensor system |
Design and Physical |
|
Housing | Black anodized aluminium |
Dimensions | Height:165mm / Diameter:100mm |
Weight | 1kg |
Transport Cover | Hood with integrated floor stand |
Mounting mechanism | Button-press quick release |
Operation |
|
Stand-alone operation | One-button operation |
Remote operation | iPad app – Apple iPad Pro® 12.9”/IOS 10 or later |
Wireless communication | Integrated wireless LAN (802.11 b/g/n) |
Internal memory | Storage for >100 setups |
Instrument orientation | Upright and upside down |
Power |
|
Battery type | Internal, rechargeable Li-Ion battery (Leica GEB121) |
Capacity | Typically, >40 setups |
Scanning |
|
Distance measurement system | High speed time of flight enhanced by Waveform Digitizing (WFD) technology |
Laser Class | Class 1 |
Wavelength | 830nm |
Field of view | 360˚ (horizontal / 300˚ (vertical) |
Range | Min. 0.6 up to 60m |
Point measurement rate | Up to 360,000 pts/sec |
Ranging accuracy | 4mm @ 10m / 7mm @20 m |
Measurement modes | 3 user selectable resolution settings |
Imagining |
|
Camera System | 15 Mpixel 3-camera system, 150Mpx full dome capture, HDR, LED flash Calibrated spherical image, 360˚x70˚ |
Performance |
|
Measurement speed | <3 min for complete full dome scan, spherical image and thermal image |
3D point accuracy | 6mm @ 10m /8mm @20 |
Environmetnal |
|
Robustness | Designed for indoor an outdoor use |
Operating temperature | +5 to +40˚c |
Dust/Humidity | Solid particle/liquid ingress protection IP54 (IEC 60529) |
Technical Specification
What's In The Box
BLK360 G1 Imaging Laser Scanner Kit
Including:
1x Leica BLK360 G1 Imaging Laser Scanner
1x Leica BLK360 G1 Transport Hood
1x GEB212 Battery Li-Ion
1x GKL312 Battery Charger
1x GEV192-9 AC/DC Adapter for GKL
1x Car Adapter for GKL, 1m
1x Leica BLK360 G1 Quick Guide
1x Leica BLK360 G1 USB Documentation Card
1x Leica Cyclone FIELD 360 Info Sheet
