Detailed Description
The Jasic TIG 400 (JT-400P) Pulse inverter is equipped with industrial grade IGBT components and an MCU chip for high accuracy and performance.
This technologically advanced inverter with a digital panel allows for software upgrades and provides 8 channel automatic storage of the welding parameters.
This modular design TIG welding system includes the trolley and water cooler as standard.
Features & Benefits
- Industrial Grade IGBT Inverter Technology
- DC Pulse TIG/MMA with VRD function
- MCU chip for high accuracy and consistency
- HF or Lift arc ignition, 2T/4T, spot-time
- Up/down slope, pre/post flow, crater/initial/weld current
- Digital panel with interface for easy software upgrades
- Gas test function in DC TIG mode
- Modular design with trolley and water cooler included
- Automatic 8 channel storage of welding parameters
- On demand fan and water cooling
- AVR Generator friendly
- Optional Foot Pedal Control
Technical Specification
Length (mm)
760
Width (mm)
360
Height (mm)
585
Weight (kg)
90
Input Voltage
AC 400V - 50/60 Hz
leff (A)
14
Input Power (kVA)
18
Current Range (A)
TIG DC 5 - 400
Duty Cycle @ 40°C
400A @ 50%
No-Load Voltage (V)
68
Efficiency (%)
85
Power Factor
0.96
Protection/Insulation Class
IP21S/F
What's In The Box
![](https://static.wixstatic.com/media/fc2fb8_d545b8aecfc1454c8317105c607fec74~mv2.png/v1/fill/w_89,h_89,al_c,q_85,usm_0.33_1.00_0.00,enc_auto/fc2fb8_d545b8aecfc1454c8317105c607fec74~mv2.png)
Inverter power source, Trolley, Water cooler, TIG torch & adaptor, Gas regulator, Earth return lead, Operating instructions.
![](https://static.wixstatic.com/media/fc2fb8_a4f113b5577a4b99b537cb919cde75f2~mv2.png/v1/fill/w_87,h_81,al_c,q_85,usm_0.33_1.00_0.00,enc_auto/fc2fb8_a4f113b5577a4b99b537cb919cde75f2~mv2.png)
Mains plug, Electrodes, TIG torch consumables, Shielding gas, Filler wire, PPE (Welding helmet, gloves, etc)
